Mercury 75 OptiMax User Manual

OPERATION
56 eng
1. Lower the outboard to the vertical operating position. Make
sure all cooling water intake holes are submerged.
26837
2. Open the fuel tank vent screw, located in the filler cap, on
manual venting type fuel tanks.
19748
3. Position the fuel line primer bulb so the arrow on the side of
the bulb is pointing up. Squeeze the fuel line primer bulb
several times until it feels firm.
27348
4. Set the lanyard stop switch to "RUN" position. Refer to
General Information ‑ Lanyard Stop Switch.
19791

Mercury 75 OptiMax Specifications

General

Engine Type	2-stroke
Displacement	1526 cc
Horsepower	75 hp
Alternator	60 amp / 756 watt
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-5750 rpm
Steering	Remote
Fuel Induction System	2-stage direct fuel injection
Shaft Length	20"
Weight	170 kg
