Component Identification
a - Top cowl
b - Auxiliary tilt switch
c - Transom brackets
d - Gearcase
e - Cooling water intake
holes
f - Trim tab
g - Anti‑ventilation plate
h - Driveshaft housing
i - Water pump indicator
hole
j - Bottom cowl
a
j
i
h
b
g
f
e
d
c
29461
GENERAL INFORMATION
eng 41
