Mercury 8 User Manual

ENGINE INSTALLATION
106
INSTALLING OUTBOARD ON TRANSOM
1. Place the outboard on the center line of the transom.
27005
2. Tighten the transom bracket clamp screws.
28501
3. Non‑power trim models ‑ To prevent a loss of the outboard,
secure the outboard to the transom with the two transom
bracket clamp screws and two mounting bolts. Drill two
7.9 mm (5/16 in.) holes through the transom bracket mounting
holes. Fasten with two bolts, flat washers, and locknuts. Use
a marine waterproofing sealer in the holes and around the
bolts to make the installation water tight. Tighten the bolts to
the specified torque.
d
a
b
c
28971
a - Bolts (2)
b - Washer (2)
c - Locknut (2)
d - Transom bracket clamp
screws (2)
Description Nm lb. in. lb. ft.
Transom bracket mounting bolts 13.5 10

Mercury 8 Specifications

General

Full Throttle RPM	5000-6000 RPM
Cylinders	2
Gear Ratio	2.08:1
Horsepower	8 HP
Starting	Manual
Shaft Length	15 in, 20 in
Fuel Tank Capacity	External
