ENGINE INSTALLATION
110
Assemble steering link rod to steering cable with flat washer and
nylon insert locknut. Tighten locknut until it seats, then back nut off
1/4 turn.
Assemble steering link rod to engine with bolt, locknut and spacer
and flat washers. Torque locknut to specifications.
Remote Wire Harness Connection
1. Remove the cover and cable receptacle bracket from the
bottom cowl.
a
28003
a - Cover
a
28107
a - Cable receptacle bracket
