MAINTENANCE
84
Tube Ref No. Description Where Used Part No.
95
2-4-C with Teflon Propeller shaft 92-802859A1
7. Install front thrust washer, propeller, rear thrust hub, and
propeller nut onto the shaft.
8. Place a block of wood between gearcase and propeller to
prevent rotation and tighten propeller nut. Secure propeller nut
to the shaft with cotter pin.
a
b
c
d
e
27094
a - Cotter pin
b - Propeller nut
c - Rear thrust washer
d - Propeller
e - Front thrust washer
Fuse Replacement ‑ Electric Start Models
IMPORTANT: Always carry spare 20 AMP fuses.

Mercury 9.9 Specifications

General

Cylinders	2
Fuel Tank	External
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Induction System	Carbureted
Alternator Amp	6 amp
Horsepower	9.9 hp
Starting	Manual
Shaft Length	15 in, 20 in
Steering	Tiller
