Section 3 - On the Water
Page 20 90-899883210 APRIL 2008
Joystick Input Boat Response
Movement
(shown from light gray to dark gray)
Boat moves aft to the port
Boat moves counterclockwise around its stern
Maneuvering with the Switchpad
!
WARNING
A spinning propeller, a moving boat, or any solid device attached to the boat can cause serious injury or
death to swimmers. Stop the engine immediately whenever anyone in the water is near your boat.
To maneuver the boat with the switchpad:
1. Activate the Total Command system.
2. Press the switchpad buttons in the direction that you want the boat to move as indicated by the arrows
on the buttons, or press the buttons in opposite corners to create rotation in the direction that you want
the boat to rotate.
Switchpad Inputs and Responses
Switchpad Input
Boat Response
Movement
(shown from light gray to dark gray)
Boat moves to starboard without rotating
