Section 4 - Specifications
Page 24 90-899883210 APRIL 2008
Batteries
The batteries must meet or exceed the following specifications for proper operation of the Total Command
system.
Parameter Specification
Total voltage output Two 12 V batteries used in series for a total 24 V for each thruster.
Type
AGM or similar fast discharge and recovery, marine or commercial type.
Sealed, no maintenance
Amp hours (C20) 100
Cold cranking amps (CCA) 1090
Reserve Capacity 200 minutes
Weight 34 Kg (75 lb)
BCI group size Group 31
Manufacturer Odyssey
Manufacturer's part number PC2150
Fuses
Thruster Series Voltage Fuse
CT60/24V 24 V 200 Amp ANL fuse
CT80/24V 24 V 200 Amp ANL fuse
CT125/24V 24 V 300 Amp ANL fuse
CT165/24V 24 V 500 Amp ANL fuse
CT225/24V 24 V 500 Amp ANL fuse
Thrusters
Thruster CT60 CT80 CT125 CT165 CT225
Nominal Voltage 24 V 24 V 24 V 24 V 24 V
Amperage 200 A 240 A 389 A 540 A 680 A
kW 4.4 5.3 8.6 11.9 14.9
Hp 5.9 7.1 11.5 15.9 22.0
Thrust kg (lb) 63 (139) 75 (165) 115 (254) 160 (353) 195 (430)
Weight kg (lb) 14.8 (32.6) 15.1 (33.3) 24 (52.9) 36 (79.4) 37 (81.6)
