34
CD756
77359
1
BCDAE
CD757
ENGINE MONITORING FEATURES
1 The appropriate light functions as follows:
A Preheat Indicator Lamp - indicates when the glow plugs, if equipped, are preheating the combustion
chambers. When the engine is cold the timed preheat period begins when the key switch is turned to RUN.
The light stays on until the preheat period is complete. The engine can be started only after the light goes out.
B Charge Indicator Lamp - indicates a problem with charging system if lamp illuminates while engine is
operating. Lamp will be on when key switch is in RUN and engine is not operating. When engine starts, light
should go off.
C Oil Pressure Warning Lamp - indicates low engine oil pressure if lamp illuminates while engine is operating.
D Coolant Temperature Warning Lamp - indicates excessive engine coolant temperature if lamp illuminates
while engine is operating.
E Water-In-Fuel Warning Lamp - indicates water is present in fuel filter and that fuel filter requires service.
