Clamp/Swivel Bracket and Driveshaft Housing

90-8M0065421 NOVEMBER 2012 Page 5A-7

Clamp Bracket Components

Ref. No. Qty. Description

Torque

Nm lb‑in. lb‑ft

1 2 Clamp bracket

2 2 Clamp screw assembly

3 2 Pad

4 1 Screw

5 1 Nut (M8) 9 80

6 2 Washer

7 1 Rod

8 2 Nut 6 53

9 2 Washer

10 1 Thrust support

11 1 Damper

12 1 Thrust rod

13 1 Knob

14 1 Tilt pin

15 1 O‑ring

16 1 Swivel bracket cap

17 1 Stopper

18 1 Steering stop lever

19 1 Pin

20 1 Spring

21 1 Bolt 6 53

22 1 Washer

23 1 Bushing

24 1 Thrust plate

25 4 Special flange head bolt 11 97

26 1 Bushing

27 1 Adjusting screw

28 1 Friction pad

29 1 Spring

30 1 Washer

31 1 Swivel bracket
