Ignition
90-8M0065421 NOVEMBER 2012 Page 2A-11
11. Apply Loctite 242 Threadlocker to the three fuel tank mounting bolts. Install the bolts and washers. Tighten the bolts to the
specified torque.
a - Fuel tank
b - Bolt and washer (M6 x 25) (3)
Tube Ref No. Description Where Used Part No.
66
Loctite 242 Threadlocker Fuel tank mounting bolts 92-809821
Description Nm lb‑in. lb‑ft
Fuel tank mounting bolt (M6 x 25) (3) 6 53
12. Secure the fuel line hose to the fuel tank with a hose clamp.
Ignition Coil Testing
Secondary Resistance
NOTE: The readings listed are taken at 20 °C (68 °F) with a digital ohmmeter. Due to the number of different manufacturers,
meters available, and temperature variance; test results may vary.
NOTE: It is not necessary to remove the ignition coil from the powerhead for testing.
1. Remove the spark plug cap from the spark plug.
2. Measure the resistance between the spark plug lead and engine ground.
a - DMT 2004 digital multimeter
b - Spark plug cap/lead
c - Black ground wire
DMT 2004 Digital Multimeter 91‑892647A01
