Gear Housing
90-8M0065421 NOVEMBER 2012 Page 6A-3
Dial Indicator 91‑58222A1
Measures distance, movement, and runout; used for drive system assembly and
engine setup
Protector Cap 91‑24161
Protects the crankshaft when removing the flywheel; use with flywheel puller
(91‑849154T 1)
Universal Puller Plate 91‑37241
Removes bearings from gears and the driveshaft
Puller 91‑27780
Removes gears, bearings, and races
Bearing Removal and Installation Kit 91‑31229A7
2966
Installs and removes the bearings in all gearcases.
91‑31229A7 Tool assembly includes the following components:
11‑24156 Hex Nut
12‑34961 Washer
91‑15755T Bearing Carrier
91‑29310 Plate
91‑29610 Pilot Plate
91‑30366T1 Mandrel
91‑31229 Puller Shaft
91‑32325T Driver Head
91‑32336 Driver Needle Bearing
91‑36379 Puller/Head Gear
91‑36569T Driver Head
91‑36571T Pilot Washer
91‑37292 Roller Bearing
91‑37311 Driver Head
91‑37312 Driver Head
91‑37323 Driver Head Rod
91‑37324 Pilot Washer
91‑37350T Pilot Mandrel
91‑38628T Puller/Driver Head
91‑52393 Driver Needle Bearing
91‑52394 Head Pull Rod
