Recoil Starter
90-8M0065421 NOVEMBER 2012 Page 8A-5
Recoil Starter Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Recoil starter assembly
2 1 Spring
3 1 Reel
4 2 Ratchet pawl
5 1 Friction plate
6 1 Screw Drive tight
7 1 Friction spring
8 1 Rope
9 1 Starter handle
10 1 Rope anchor
11 1 Rope anchor plate
12 1 Starter seal
13 3 Bolt (M6 x 60) 6 53
14 3 Washer
15 1 Clamp
