Mercury FourStroke 2.5 User Manual

Carburetor and Fuel Pump
90-8M0065421 NOVEMBER 2012 Page 3A-7
Fuel Tank Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Fuel tank
2 1 Cover
3 3 Spacer
4 3 Washer
5 3 Bolt 6 53
6 1 Seal
7 1 Caution decal
8 1 Fuel cap
9 1 Gasket
10 1 Hook
11 1 Fuel hose to fuel pump inlet
12 2 Clip
13 1 Fuel valve
14 2 Rubber seal
15 1 O‑ring
16 1 Fuel valve knob
17 2 Clip
18 1 Fuel hose
19 1 Clip
