Mercury FourStroke 2.5 User Manual

Powerhead
90-8M0065421 NOVEMBER 2012 Page 4A-11
Oil Pan Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Oil pan
2 1 Oil level sight gauge
3 3 Dowel pin
4 1 Drain bolt 20 177
5 1 Washer
6 8 Bolt (M6 x 35) 11 97
7 1 Oil seal
8 1 O‑ring
9 2 Oil seal
10 1 Driveshaft seal housing
11 2 Bolt (M6 x 20) 6 53
12 1 Oil pan gasket
13 1 Oil filler cap
14 1 O‑ring
15 2 Bolt (M6 x 20) 6 53
16 1 Hose
17 2 Clamp
18 1 Starter bracket
19 2 Damper
20 2 Collar
