Mercury FourStroke 3.5 User Manual

Powerhead
Page 4A-44 90-8M0065421 NOVEMBER 2012
17. Secure the choke cable with the J‑clamp and the washer and bolt.
a - J‑clamp
b - Washer and bolt
securing choke cable
c - Fuel hose to the fuel
pump
d - Fuel shutoff valve
e - Fuel shutoff valve
knob
f - Fuel hose from the
fuel pump
g - Bracket
18. Route the fuel hoses as shown.
49932
19.
Install the fuel tank and recoil starter. Refer to Section 8A ‑ Recoil Starter.
20.
Fill the crankcase with the specified engine oil. Refer to Section 1A ‑ Master Specifications.
49878
f
c
e
d
a
b
e
g
