PROBLEM TACHOMETER DISPLAY
SPEEDOMETER
DISPLAY
FAULT ‑ MAT ×
FAULT ‑ TPS ×
Oil level ‑ OK x x
Oil level LOW ‑ Check OIL x x
NOTE: Depending on the engine model and vessel options, not all screens will
apply.
FAULT
RESERVE
FAULT
FAULT
HORN
90% REMAINING
OIL PUMP
INJECTOR
46351
OVERHEAT
PRESSURE
OVERSPEED
WATER
7500
RPM
IN FUEL
IMPORTANT: Refer to the Operation and Maintenance Manual for further
explanation of the problem and the correct action to take. Contact the dealer if
the problem persists.
1.
OVERHEAT: The engine has overheated.
2.
PRESSURE: There is insufficient water pressure in the cooling system.
3.
OVERSPEED: Engine speed exceeded the maximum allowable RPM.
4.
WATER IN FUEL: Water in the water‑separating fuel filter reached the full
level.
5.
FAULT ‑ HORN: The warning horn is not functioning correctly.
6.
RESERVE OIL LOW ‑ 2‑Stroke outboard only: Oil level is critically low
in the engine‑mounted oil reservoir tank.
7.
FAULT ‑ OIL PUMP: The oil pump has stopped functioning electrically.
No lubricating oil is being supplied to the engine.
8.
FAULT ‑ INJECTOR: One or more of the fuel injectors have stopped
functioning electrically.
