TROLLING MOTOR INSTALLATION AND OPERATION
12
DEPLOYING THE MOTOR
!
CAUTION
Moving
parts,
such
as
hinges
and
pivot
points,
can
cause
serious
injury.
Keep
away
from
moving
parts
when
stowing,
deploying,
or
tilting the motor.
1.
Firmly
grasp
the
column
and
press
down
on
the
tilt‑positioning
pin.
37985
Tilt‑positioning pin
2.
Adjust the angle of the motor to the desired postion.
37986
Angled position
15
