23
Chapter 4 Congure the Router in Wireless Router Mode
4. 3. 2. Guest Network
Guest Network allows you to provide Wi-Fi access for guests without disclosing your host
network. When you have guests in your house, apartment, or workplace, you can create a
guest network for them. In addition, you can customize guest network settings to ensure
network security and privacy.
Create a Guest Network
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Wireless or Advanced > Wireless > Guest Network.
3. Enable the Guest Network function.
4. Create a network name for your guest network.
5. Select the Security type and create the Password of the guest network.
6. Click SAVE. Now you guests can access your guest network using the SSID and
password you set!
Customize Guest Network Options
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Advanced > Wireless > Guest Network. Locate the Guest Permissions section.
3. Customize guest network options according to your needs.
Allow guests to see each other
Tick this checkbox if you want to allow the wireless clients on your guest network to
communicate with each other via methods such as network neighbors and Ping.
Allow guests to access my local network

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MR70X and is the answer not in the manual?

Mercusys MR70X Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Product typeTabletop router
Product colorBlack
LED indicatorsPower, WLAN
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)1775 Mbit/s
WLAN data transfer rate (first band)1201 Mbit/s
WLAN data transfer rate (second band)574 Mbit/s
Antennas quantity4
Antenna gain level (max)5 dBi
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Number of guest networks (2.4 GHz)1
Power source typeDC
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Mobile network generation-
Cables includedLAN (RJ-45)
Firewall securitySPI Firewall, IP and MAC Address Binding
Security algorithmsWPA-PSK, WPA2-PSK, WPA3
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth171.6 mm
Width208.8 mm
Height41.7 mm
