IOM-HAPI-MADM/MADS
The MADI optional Module card (
MADM
- Multimode /
MADS
– Single mode) provides a channel count
of 64 inputs and 64 outputs @1FS
IOM-HAPI-MADM/MADS Features
• MADI Optical and Coaxial inputs and outputs
• 64 discrete channels of digital input and output (extended mode) at 1FS
• Up to 384 kHz sampling rate
• 24-bit resolution
• Fully compliant MADI (AES 10-1991)
• 2 BNC and 1 SC connectors (Multimode or single mode)
Single mode fibers have a lower power loss characteristic than multimode which means that it supports
longer runs but single mode fibers are more expensive. The multimode version (IOM-HAPI-MADM) is
the most widely used optical MADI connection, but for fiber lengths of more than 600m Merging
Technologies recommends to use the single mode version (IOM-HAPI-MADS).
HORUS-RSGP
For installations where extended control is needed, Horus owners can add 8xGPIO and
RS-422 (Sony 9pin) connectivity with this easy to install option
