7
41A2780
Cable Sprocket Bracket
41B4494-1
2-Conductor Bell Wire
White & White/Red
41A3489
Trolley
41A4353-1
Header Bracket
41A3611-2
Chain Dispensing Carton
178B35
Curved Door
Arm Section
178B34
Straight Door
Arm Section
Safety Labels
and
Literature
12B776
Hanging Brackets
UP
CEILING MOUNT ONLY
41A5047-1
Door Bracket
41A5273-21
Multi-Function
Door Control Panel
LOCK
LIGHT
1B3117
Rail Center Section
TO GARAGE DOOR
183B110
Rail End Section (each)
SECURITY
®
Multi-Function Remote Control (2)
Motor Unit and Light Lens
(Light Lens Part Number: 108D78)
41A4371-2
Sprocket Cover
29B137
Remote Control
Transmitter Visor Clip
83A11-2
Rail Grease
Your garage door opener is packaged in two cartons which
contains the motor unit and the parts illustrated below. Note that
accessories will depend on the model purchased. If anything is
missing, carefully check the packing material.
Parts may be stuck in the foam. Hardware for assembly and
installation is shown on the next page. Save the carton and
packing material until installation and adjustment is complete.
Carton Inventory
Chain Pulley
Bracket
41A2780
41A2780
Chain Sprocket Bracket
41A273-21LMK
Multi-Function
Door Control Panel
973LMK
SECURITY✚
®
Multi-Function Remote Control (2)
To Next Page
