Merrychef 402s - Oven Operation and Controls; Control Panel Overview

10
CAT 005
CAT 006
CAT 007
CAT 008
CAT 001
CAT 002
CAT 003
CAT 004
CATEGORIES
DISPLAY PANEL
Shows the principal functions of the oven.
Whencooking,thetimeremainingcountsdown.
Alsodisplayserrormessagesandoventemperature.
Whenstoringandrecallingaprogramthedisplay
indicatestheprogramnumberanddetails.
FUNCTION PADS
The function pads select options shown in the DISPLAY
PANEL.
CONTROL PANEL
FUNCTION PADS
DISPLAY PANEL
MenuKeY
SOCKET
CANCEL PADCOOL DOWN
PAD
FUNCTION PADS
MenuKey 2
TheMenuKeySystemautomaticallychangesallthe
cookingprogramswithanelectronickeyandallows
programnamestobeidentied
COOL DOWN PAD
Puts the oven into Cool Down Mode, see Cleaning 2
page 20.
CANCEL PAD
Cancelsalltimedcookingcycles,pre-programmed
operationsandstopsthemicrowaveenergy.Itdoesnot
altertheoventemperature.Iftheovenishot,foodwill
continuetocookandshouldberemovedfromtheoven
immediately.Thispadwillalsocancelanyincorrect
operations.Itwillnoteraseprograms.
FUNCTION PADS
DisplayPanelErrormessages
Message
Condition
Possible cause
ERROR MAGNETRON 1
ERROR MAGNETRON 2
Magnetron 1 has overheated
Magnetron 2 has overheated
ERROR MAGNETRON 1 & 2
Magnetron 1 and 2 have
overheated
CAVITY SENSOR ERROR
Cavitytemperatureexceeds
morethan50°Cabove
PREHEATtemperature
setting during cook cycle
BlockedAirlter(s)
Oven located near hot air sources
Ovenbeingusedempty
Call Service Engineer
Indicatescombustion(re)inovencavity
