Merrychef 402s User Manual

9
AIR OUTLETS
These vents on the rear panels enable air which has
beenusedtocoolinternalcomponentstoescape.It
willnotallowmicrowaveenergytoescapeintothe
environment.Theymustbekeptfreefromobstruc
-
tion.
OVEN CAVITY
Thecavityisconstructedfromstainlesssteeland
vitreousenamelledpanels.Itmustbekeptclean
(seeCLEANING).
CONVECTION FAN, GREASE FILTER & CATA
-
LYTIC CONVERTOR
The convection fan, which is located behind the
catalyticconvertorpullsairinthroughthelter
whichremovesthemajorityofthesmokefromthe
airow.Theairisthenheatedandreturnedtothe
cavitythroughtheimpingerplatestoproducean
evenheatpatternintheoven.Thislayoutminimises
areas where grease build up can occur. Great care
should be taken when cleaning this area of the oven
-pleasenotethecleaningrequirementsonsee
CLEANING.
Themetalgreaseltergrillcoveringthefanmustbe
keptcleanandfreeofdebris(SeeCLEANING)
AIR INLET FILTERS ( LEFT & RIGHT )
Situated at the left and right hand side of the base
atthefront.Thesearepartoftheventilationsystem
andmustbekeptfreeofobstructionandcleanedon
a daily basis.
DOOR HANDLE
This is a rigid bar which is pulled downwards and
towards you to open.
CONTROL PANEL
See page 10.
ON/OFF SWITCH
WhenswitchedON,thecontrolpanelwillilluminate.
Thefanandventilationsystemwillalsooperate.
RATING PLATE
Found on the rear panel, this states the serial
number,modeltype&electricalspecications.
DOOR
Thisisaprecision-madeenergybarrierwiththreemi
-
crowavesafetyinterlocks.Itmustbekeptclean(see
CLEANING section). The door should NOT be used
to support heavy dishes.
DOOR SEALS
These ensure a tight seal around the door. They
should be kept clean and checked regularly for signs
ofdamage.Attherstsignofweartheyshouldbe
replaced by a Merrychef approved Service Agent.
STEAM VENT(onrearofoven)
Thisenablessteamtoescapeandpreventsbuildup
ofcondensation.Itwillnotallowmicrowaveenergyto
escape.
MenuKey 2
Changestheprogramsontheoven(SeeMenuKey
sectionfordownloadingprogramsonaMenuKey).
RACK
Shouldberemoveddailyforcleaning
(seeCLEANINGsection).
1
2
3
4
5
7
8
9
10
11
12
6
13
MAIN FEATURES
3
6
9
2
4
127
5 10 4
Rear view
13
11
8
1
1
