7 Preparing the appliance for use
Back to contents >
Merrychef conneX
®
Installation and User Manual
35
N
L2
Electrical
Supply
L1 & L2 From 3
Phase Supply
Electrical
Supply
L1 & L2 Split
Phase Supply
US and Canada
L1
N
L3
L2
Earth (GND)
Earth connection
is essential
L1
Earth connection
is essential
Earth (GND)
REAR VIEW OF PLUG
Plug: 2 Pole 30A
NEMA L6-30P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 30A
NEMA 6-30P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 20A
NEMA 6-20P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 15A
NEMA 6-15P
L1 + L2 + GND
L2
L1
L2
L1
L2
L1
L2
L1
REAR VIEW OF PLUG
Plug: 2 Pole 30A
NEMA L6-30P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 30A
NEMA 6-30P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 20A
NEMA 6-20P
L1 + L2 + GND
REAR VIEW OF PLUG
Plug: 2 Pole 15A
NEMA 6-15P
L1 + L2 + GND
L2
L1
L2
L1
L2
L1
L2
L1
~240V
~208V
