9. HOW TO OPEN AND CLOSE LOOPER
COVER
(1) OPEN LOOPER COVER
* Push the looper cover to the right as far as it will
go.
* Pull looper cover down toward you.
(2) CLOSE LOOPER COVER
* First pull the looper cover upward and then slide it
to the left until it locks.
Note : The looper cover has a safety switch and
the machine will not sew if the looper cover
is open.
8. REMOVAL AND REPLACEMENT OF
CHIP BOX
(1) REPLACEMENT
* Position the machine so the front is nearly
aligned with the
edge of the table.
*
Insert the chip box under the looper cover. Be
sure the left side of chip box is mounted near the
cutter where the scraps drop.
(2) REMOVAL
* To remove, hold the chip box as shown and pull it
outward.
(3) SPOOL CAP
Spool cap
Thread spool
Press in
* When using a regular thread spool, fit the spool
cap supplied with the machine onto the thread
spool as shown at right.
Be sure to turn off power switch.
Be sure looper cover is closed when sewing.
2
1
1
2
