T-40 User’s Manual
3
Paper thickness
0.06 mm~0.10 mm thermal paper
Power
supply
Input
100-240V AC, 50-60 Hz
Output
24V ± 5% DC, average current 2A
External or not
External power adapter
Human-machine
interface
Power switch
Support
Button
Support
LED
Support, including POWER LED and ERROR LED
Buzzer
Support, 24V buzzer
Reliability
Lifetime of print head
≥150Km (standard test sample with 12.5% duty ratio)
Lifetime of cutter
2,000,000 cuts (standard test condition)
MCBF
70,000,000 lines
MTBF
360,000 hours (main control board)
Operation temperature and humidity
5°C～45°C， 20%～90% RH(40°C)
Storage temperature and humidity
-40°C～60°C， 10%～90% RH(40°C)
Overall dimensions
127mm(L)*127mm(W)*134mm(H)
Functions
Saving paper
Support
Button configuration
Support (configure the printer without computer)
Right-up-side printing
Support
Water mark printing
Support
Gray scale printing
Support
Table 2.1-1 Technical specifications
2.2 Cutter parameters
Item
Parameter
Remarks
Cutting method
Sliding blade
Cutting time
500 ms
The time of one cut
Cutting interval
3 s
20 cuts/minute (Max.)
Applicable paper types
0.06 mm~0.10 mm thermal paper
Operation voltage
24V DC
Max. operation current
1.2A
Operation voltage 24V DC
Cutter lifetime
2,000,000 cuts
Standard test condition
Table 2.2-1 Technical parameters of cutter
2.3 Paper specification
2.3.1 Parameters of continuous paper
Ø Paper type: thermal paper
Ø Paper supply mode: paper roll
Ø Paper width: 57.5/80/82.5 mm
Ø Paper thickness: 0.06 mm-0.10 mm
Ø Thermal layer: outward
Ø Paper roll specification: paper roll OD Max ф83 mm, core ID Min. ф12.8 mm
