4 Functionality Page 11 of 25
COM200 module - Product Manual 1.0 MetCom Solutions GmbH
4 Functionality
4.1 Data Exchange support
The COM200 module is based on IP network and SMS services. The DLMS protocol is
used for data exchange between electricity meters and HES. The HES acts as DLMS client
and the E-meter as DLMS server. The following communication services are provided:
•
GPRS
•
CSD/SMS (Wake-up)
Two operating modes can be used:
•
Pull mode
•
Push mode
The “Pull” mode is initiated by the HES. It is used for collecting data from meters or sending
commands to meters and consumer’s interface. The “Pull” is using following DLMS services:
•
OPEN
•
RELEASE
•
GET or SET
•
Action
The “Push” mode is initiated by the meter to send critical information such as Alarms and so on
to the HES. The DATA-NOTIFICATION service of DLMS is used in this mode. Following table
shows the DLMS services in Pull and Push modes for IP-based or SMS communication.
Operating Mode
DLMS Services
IP Communication SMS Communication
Pull
GET, SET, ACTION
(Confirmed)
SET, ACTION
(Unconfirmed)
Push
DATA-NOTIFICATION
(Unconfirmed)
DATA-NOTIFICATION
(Unconfirmed)
4.2 Communication protocols
Using the COM200 module the MCS301 meter can be readout using:
•
DLMS/COSEM protocol
•
EN62056-21 protocol
Up to 3 sockets are supported. 2 sockets can be used in parallel
•
Socket 1: address: Default 4059 (for DLMS/COSEM communication) or
address: Default 4000 (for EN62056-21 communication)
•
Socket 2: address: Default 4059 (for DLMS/COSEM communication)
•
Socket 3: address: Default 4060 (for DLMS/COSEM communication)
