Metcom Solutions COM200 Series User Manual

10 Technical data Page 25 of 25
COM200 module - Product Manual 1.0 MetCom Solutions GmbH
10 Technical data
Housing
Connection type
Dimensions
Material
Environmental conditions
Plug ‘n’ Play
Module, which fit in the
MCS301 meter
109 x 62 x 24mm
Polycarbonate (Lexan), partly glass-fiber reinforced, flame-
retardant, self-extinguishing plastic, recyclable
MID M1
Frequency
50 or 60 Hz ±5%
Power supply
Type
self-consumption
Supported from the meter
< 2 W, 20-40V
Com
munication
module
Cellular
SIM card
GSM/GPRS:
Telit GL865 Dual Band (900/1800 MHz)
Telit GL865 Quad (900/1800MHz and 850/1900 MHz)
Mini SIM card
Interface
Meter interface
SPI interface
User interface
Configuration
Optical or electrical interface using the meter tool Blue2Link tool
Temperature /
Environmental
influences
Operation/storage temp.
Humidity
Ingress protection
Insulation Class
- 25°C ... +70°C / - 40°C ... +85°C
95% rel. humidity, non-condensing
IP20
Class II to IEC 62052-11
Electr
omagnetic
Compatibility
Surge withstand 1.2/50 µs
Insulation strength
Environmental conditions
6 kV, Rsource = 40 Ω, optional 12kV
4 kVrms, 50 Hz, 1 min.
MID E2
Protocol
DLMS/COSEM
EN62056-21
Security
Watchdog
Restart Modem in a fixed time every day
F
unctionality
Sockets
Push mode
Signal quality
Up to 3 Sockets addresses for parallel communication through:
EN62056-21 or DLMS/COSEM communication protocols
Push to FTP server, SMS or Email
Different Trigger events, like scheduler or alarm
Signal strength, Provider, etc.
Antenna connection
Internal
External
Connector type: U.FL
Connector type: SMA (Female) or FME (Male)
Frequency band
s
Dual band
Quad Band
900 / 1800 MHz
850 / 1900 MHz
Weight
0,1 kg
Node sayaç Çözümleri Ltd. Şti.
Metering Solutions
www.node.com.tr
