Metra Electronics 95-2005B - Deville (DHS, DTS) 2000-2005

95-2005B
4
Seville 1998-2005 /
Deville (console shift) 1996-1999
4. Remove (3) 9/32 screws:
• (1) From the top (Figure C) and
• (2) From the bottom to remove radio.
(Figure D)
5. Remove the (2) retaining nuts securing the
radio and climate control to the factory
bracket assembly and slide the climate
control outward. (Figure E)
Continue to kit preparation
(Figure E)
(Figure D)
(Figure C)
Deville (DHS, DTS)
2000-2005
1. Unsnap and remove
panel surrounding
climate controls and
radio. (Figure A)
2. Depress clips on
both sides of radio
and pull out to
remove. (Figure B)
Continue to kit
preparation
(Figure B)
(Figure A)
Remove 2 Retaining Nuts
One Per Side
Remove (2) retaining nuts,
per side
Dash Disassembly
