Metra Electronics 95-2005B - Kit Preparation; Eldorado 1996-2002; Seville 1996-1997

95-2005B
5
Eldorado 1996-2002 / Seville 1996-1997
1. Remove all tabs except the ones marked S-E from the radio housing. (Figure A)
2. Cut the front tab from bottom of the radio brackets armature on both sides.
(Figure B)
3. Attach the radio brackets to the radio housing. (Figure C)
4. Slide the climate control assembly into the bracket/housing assembly and
attach with the factory hardware. (Figure C)
Continue to kit assembly
(Figure C)
(Figure B)
(Figure A)
98-05S
98-05S
98-05S
S-E
S-E
CUT
CUT
CUT
CUT FRONT TAB HERE
CUT FRONT TAB HERE
Cut front tab here
Cut front tab here
(full view)
Bolt
Bolt
Kit Preparation
