Metra Electronics 95-2005B - Deville (DHS, DTS) 2000-2005

95-2005B
7
Deville (DHS, DTS) 2000-2005
1. Remove all tabs from the radio housing top. (Figure A)
2. Attach the radio brackets to the radio housing. Leave all side tabs on the radio
brackets attached, but cut away the plastic armature below each bracket at the
bottom of both sides. (Figure B)
3. When installing the 95-2005 assembly into the dash, use the supplied (4) #8 x
3/8” Phillips screws, to the locations shown. (Figure C)
Continue to kit assembly
(Figure C)
(Figure B)
(Figure A)
98-05S
98-05S
98-05S
S-E
S-E
CUT
CUT
CUT
CUT
CUT
Kit Preparation
