4
Dash Disassembly
Ford Five-Hundred 2005-2007/Taurus 2008-2009,
Mercury Montego 2005-2007/Sable 2008-2009
1. Unclip and remove the small
rectangular trim around shift lever.
(Figure A)
2. Unclip and remove the entire panel
(including cup holders) surrounding
the shift lever. (Figure B)
3. Remove (2) 9/32” screws at the
bottom of the center radio/climate
control panel. (Figure C)
4. Unclip and remove the center
panel. (Figure D)
5. Remove (4) 9/32” screws from the
radio to remove. (Figure E)
Continue to kit assembly
(Figure D)
(Figure E)
Ford Mustang
2005-2009
(Figure D)
(Figure E)
(Figure B)
(Figure C)(Figure A)
To Next Page
