5
Dash Disassembly
1. Unsnap and remove entire panel
surrounding the radio and climate
controls. (Figure A)
2. Remove (4) 9/32” screws to remove
the factory radio. (Figure B)
Continue to kit assembly
Ford Fusion 2006-2009
Mercury Milan 2006-2009
Ford Freestyle 2005-2007
Ford Taurus X 2008-2009
(Figure B)(Figure A)
1. Unclip and remove entire panel
surrounding the radio and A/C
controls. (Figure A)
2. Remove (4) 9/32” screws from radio
to remove. (Figure B)
Continue to kit assembly
(Figure B)(Figure A)
To Next Page
