6
Dash Disassembly
1. Unsnap and remove entire panel
surrounding the radio and climate
controls. (Figure A)
2. Remove (4) 9/32” screws to remove
the factory radio. (Figure B)
Continue to kit assembly
Ford Freestar 2004-2007
Mercury Monterey 2004-2007
Ford Focus
2005-2007
(Figure B)(Figure A)
1. Unsnap and remove entire panel
surrounding the radio and climate
controls. (Figure A)
2. Remove (4) 9/32” screws to remove
the factory radio. (Figure B)
Continue to kit assembly
(Figure B)(Figure A)
