Metra Electronics 95-7313 - 2003-2008 Hyundai Tiburon Dash Disassembly

95-7313
2
DASH DISASSEMBLY
2003-2008 HYUNDAI TIBURON
Disconnect the negative battery terminal to
prevent an accidental short circuit.
1
A
Unclip and remove the radio trim panel starting
with the bottom edge.
(Figure A)
2
Remove (2) Phillips screws securing radio.
3
