Metra Electronics 95-7313 - 2002-2005 Hyundai Sonata; 2001-2005 Kia Optima Dash Disassembly

95-7313
3
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio. (Figure A)
2
2002-2005 HYUNDAI SONATA
Remove (4) Phillips screws securing
radio.
3
The rear support bar in the sub dash
will need to be cut and removed for
aftermarket radio clearance.
(Figure B)
4
DASH DISASSEMBLY
A
2001-2005 KIA OPTIMA
B
