95-7362B
2
1. Remove trim panels from each
side of center console. (Figure A)
2. Remove (4) Phillips screws from
radio trim panel. Gently pry radio
trim panel from dash. (Figure B)
3. Remove (4) Phillips screws
securing radio chassis to sub dash.
(Figure C)
Continue to kit assembly
Dash Disassembly
(Figure A) (Figure B) (Figure C)
To Next Page
