Metra Electronics 95-7504 - Kit Assembly; Double DIN Radio Provision

3
95-7504 KIT ASSEMBLY
A
B
C
DOUBLE DIN RADIO PROVISION
Slide the Double DIN radio into the
bracket/radio housing assembly and
secure the radio to the assembly using
the screws supplied with the radio.
Snap the trim plate onto the front of
the radio housing.
(Figure B)
2
Attach the (2) PC-7503 panel clips to
the rear of the radio housing.
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure A)
1
