95-7504 KIT ASSEMBLY
4
A
B
STACKED ISO UNITS PROVISION
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure A)
1
Slide the stacked ISO units into the
bracket/radio housing assembly and
secure the units to the kit using the
screws supplied with the units. Snap
the trim plate onto the front of the
radio housing.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
C
Attach the (2) PC-7503 panel clips to
the rear of the radio housing.
(Figure C)
3
