Metra Electronics 99-3106 - Dash Disassembly Procedures; 2003-2005 Saturn Ion Dash Disassembly; 2000-2005 Saturn LS Dash Disassembly

99-3106
1
Disconnect the negative battery
terminal to prevent an accidental short
circuit.
1
Unclip and remove the trim panel
surrounding the radio.
(Figure A)
2
2003-2005 SATURN ION
Remove (2) 9/32” screws from radio to
remove.
(Figure A)
3
DASH DISASSEMBLY
A
2000-2005 SATURN LS
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
B
Unclip and remove the trim panel
surrounding the radio.
(Figure B)
2
Remove (2) 9/32” screws from radio
to remove.
(Figure B)
3
