Metra Electronics 99-3106 - 2000-2002 Saturn SL Dash Disassembly

99-3106
2
DASH DISASSEMBLY
2000-2002 SATURN SL
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
A
Remove (4) Phillips from panel below
steering column and unclip and
remove.
(Figure A)
2
B
Remove (4) Phillips screws from the
steering column trim panel and
remove.
(Figure B)
3
Remove (2) screws from the end
cap/vent on the left side of the
steering column then unclip and
remove.
(Figure C)
4
Unclip and remove the entire dash
panel surrounding the radio, instru-
ment cluster and a/c controls.
(Figure D)
5
Remove (2) 9/32” screws securing
the head unit to remove. (Figure D)
6
C
D
