99-3106
3
DASH DISASSEMBLY
2002-2005 SATURN VUE
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
A
Unsnap and remove shifter trim
panel.
(Figure A)
2
Remove (4) 9/32” screws from the
dash pocket and remove.
(Figure A)
3
Unsnap and remove panel surround-
ing radio and a/c controls.
(Figure A)
4
Remove (2) 9/32” screws from radio
to remove.
(Figure A)
5
To Next Page
