2
1. Using Metra’s 86-5618, pull the factory
radio from the dash and disconnect the
wiring. (Figure A)
2. Remove (2) 7/16” hex bolts from inside
the dash cavity and remove the radio
subdash bracket. (Figure B)
Note: The threaded studs from under this
bracket will also need to be removed for
the aftermarket radio to clear .
Continue to Kit Assembly
ALSO REMOVE (2) THREADED STUDS FROM UNDER BRACKET
7/16” (2)
HEX BOLTS
RADIO SUB-DASH BRACKET
(Figure B)(Figure A)
DASH DISASSEMBLY
