Metra Electronics 99-5838CH - Page 3

REV. 10/28/2020 INST99-5838CH
DASH DISASSEMBLY (CONT.)
3
(Figure F)
(Figure D) (Figure E)
4. Remove the rubber tray cover in front
of the shifter, and then remove the (2)
9/32” screws exposed. (Figure D)
5. Unclip and remove the front side panels
from each side of the center console.
(Figure E)
6. Remove the (2) 9/32” screws from each
side of the center console. (Figure F)
Continued on the next page
