AXXESS INTERFACE INSTALLATION
9
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains SYNC
• Retains the factory backup camera
• Retains balance and fade
• Micro-B USB updatable
INTERFACE FEATURES
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• Axxess interface (built into the touchscreen display)
• 5838 harness
• HVAC interface
• HVAC interface harness
• 16-pin harness with stripped leads
• 12-pin backup camera harness
• 4-pin harness with yellow RCA jacks
• Female 3.5mm connector with stripped leads
Connections .............................................................................................................................10-11
Installation .................................................................................................................................. 12
Programming ...............................................................................................................................13
Extra features (SYNC)...................................................................................................................13
Touchscreen display operation ..............................................................................................14-15
Steering wheel control settings ............................................................................................16-17
Troubleshooting .......................................................................................................................... 18
INTERFACE COMPONENTS
TABLE OF CONTENTS
