Metra Electronics 99-6510 - Dash Disassembly Procedures; Chrysler Aspen 2007 Dash Removal; Dodge Durango 2005-2007 Dash Removal; Dodge Charger;Magnum 2005-2007 Dash Removal

(Figure A) (Figure C)
(Figure B)
1. Remove (2) 7 mm screws from the
inside of the pocket facing upward.
(Figure A)
2. Unclip and remove the entire trim
panel surrounding the radio and
climate controls. (Figure B)
3. Remove (4) 7 mm screws securing
radio to dash and remove radio.
(Figure C)
Continue to kit assembly
Chrysler Aspen 2007
Dodge Durango 2005-2007
1. Unclip and remove entire panel
surrounding radio and climate
controls, including A/C vents.
(Figure A)
2. Remove (4) 7 mm screws securing
radio to dash and remove radio.
(Figure B)
Continue to kit assembly
Dodge Charger/Magnum
2005-2007
(Figure A)
(Figure B)
Dash Disassembly 99-6510
