Metra Electronics 99-6510 - Chrysler 300 2005-2007 Dash Removal; Dodge Ram 1500;2500;3500 (No Console) Dash Removal

1. Unclip and remove entire panel
surrounding radio and climate
controls, including A/C vents and
clock. (Figure A)
2. Remove (4) 7 mm screws securing
radio to dash and remove radio.
(Figure B)
Continue to kit assembly
1. Open cup holder and remove (2)
Phillips screws facing up on front
edge of radio/climate control panel.
(Figure A)
2. Unclip and remove entire panel
surrounding radio and climate
controls, including A/C vents.
(Figure B)
3. Remove (4) 7 mm screws securing
radio to dash and remove radio.
Continue to kit assembly
Chrysler 300
2005-2007
Dodge Ram 1500
(without center console)
/
Ram 2500/3500 2006-2008
(Figure A)
(Figure B)
(Figure A)
(Figure B)
Dash Disassembly 99-6510
