1
2001-2006 HYUNDAI ELANTRA
A
99-7313
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove (2) Phillips screws from
under the instrument cluster.
2
Remove ashtray then remove (2)
Phillips screws in ashtray cavity.
3
Unclip and remove panel surround-
ing radio and remove the bezel.
(Figure A)
Remove (4) Phillips screws securing
radio.
4
5
DASH DISASSEMBLY
