2003-2008 HYUNDAI TIBURON
A
B
2
99-7313
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the radio trim
panel starting with the bottom edge.
(Figure A)
2
Remove (2) Phillips screws securing
radio.
3
DASH DISASSEMBLY
NOTE: For the 2003-2008 Hyundai
Tiburon applications you will need to
cut and remove the bottom mount-
ing tabs on the DDIN brackets.
(Figure B)
To Next Page
