3
2002-2005 HYUNDAI SONATA
B
A
99-7313
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove entire panel sur-
rounding radio.
(Figure A)
2
Remove (4) Phillips screws securing
radio.
3
NOTE: The rear support bar in the
sub dash will need to be cut and
removed for aftermarket radio clear-
ance.
(Figure B)
DASH DISASSEMBLY
2001-2006.5 KIA OPTIMA
(2006 OPTIMA EARLY PRODUCTION MODELS ONLY)
To Next Page
