Metra Electronics 99-7524B - Kit Assembly; ISO DIN radio provision with pocket; ISO DDIN radio provision

99-7524B
Kit Assembly
8
ISO DIN radio provision with pocket
1. Mount the pocket to the radio
brackets with (4) #8 x 3/8” Phillips
screws supplied. (Figure A)
2. Remove the metal DIN sleeve and
trim ring from the aftermarket
radio.
3. Slide the radio into the bracket/
pocket assembly, and then secure
with the screws supplied with the
radio. (Figure B)
Continue to the Wiring Installation
ISO DDIN radio provision
1. Attach the radio brackets to the
radio using the screws supplied
with the radio. (Figure A)
Continue to the Wiring Installation
(Figure A)
(Figure B)
(Figure A)
